Life Racing x10 Expansion Unit | High-Speed ECU I/O Module

Maximize your vehicle's potential with the Life Racing x10 Expansion Unit, a high-performance microprocessor-controlled module designed to expand the capabilities of any Life Racing ECU. By providing a dedicated master/slave link, the x10 allows you to add a significant number of sensors and drivers to your system without the complexity of a secondary standalone controller.

Powerful Output Expansion

The x10 provides a versatile array of drivers to manage everything from auxiliary pumps to complex electronic throttles:

• 10 Configurable PWM Outputs: General-purpose Pulse Width Modulated power outputs for precise control of solenoid valves, fans, and pumps.

• Dual Full Bridges: Features 2 full bridges (configurable as 4 half bridges or 4 PWMs), making it ideal for managing additional Drive-by-Wire (DbW) motors or high-current bidirectional actuators.

Precision Input Suite

Enhance your data acquisition with a flexible input rail designed for motorsport-grade sensors:

• 10 Analogue Sensor Inputs: User-configurable inputs for pressure, temperature, or position sensors.

• High-Speed Speed Sensing: Includes support for up to 6 bipolar, inductive, or Hall Effect inputs, allowing for expanded wheel speed monitoring or secondary engine position tracking.

Advanced Connectivity & Communication

• Master/Slave CAN Link: Features a dedicated CAN 2.0B interface for a high-speed custom link to any Life Racing ECU, ensuring low-latency data transfer.

• Secondary CAN Interface: A second CAN 2.0B interface is available for integration with third-party logging systems or additional controllers.

• Ethernet Support: 100MHz full duplex Ethernet ensures fast and reliable firmware upgrades.

Motorsport-Spec Engineering

Built to survive the most demanding racing environments, the x10 shares the same pedigree as our flagship ECUs:

• Chassis: CNC machined aluminium case, "O" ring sealed to IP67 standards for total protection against water and dust.

• Connector: Utilizes a reliable 35-Way AMP sealed connector for secure, vibration-proof wiring.

• Power Protection: 6V to 32V input range with reverse polarity protection and a regulated 5V sensor supply with short-circuit protection.

• Compact & Lightweight: At only 360 grams and 130 x 121 x 43 mm, it is easy to package in any chassis.
